Product

1. Installation position: on the oil tank cap, on the raised seat or on the upper side wall of the oil tank.

2. Environmental requirements: -30 ℃ to+70 ℃(can be customized according to user needs to support up to -45 ℃ to+70 ℃); Work environment requirements:- 30℃～+125℃(customizable according to user needs, can support up to -45 ℃~+125 ℃).

3. Relative humidity: no more than 95% at +20 °C.

4. Protection level: IP55(Customizable according to user requirements). Scope of application: Altitude 0~4000m.

5. Power frequency withstand voltage: normally open contact 2000V/min, normally closed contact or single pole double throw contact: phase to phase 1000V/min, ground 2000V/min.

6. Insulation performance: normally open contact 2500V, 1000M Ω, normally closed contact or single pole double throw contact: phase to phase 1000V, 500M Ω, ground 2500V, 1000M Ω.
